ABB ACS-AP-W / ACS-AP-S / ACS-AP-I / ACS-AP-H Assistant Control Panels – Graphical HMI for ACS880/580/380 – New Original

Product Overview

Original ABB ACS-AP series assistant control panels for ACS880, ACS580, ACS380, ACQ810, and ACSM1 series drives. High-resolution graphical display with context-sensitive help and assistant-guided start-up. Connects via RJ-45 to drive front panel port with plug-and-play operation. Supports parameter copy, real-time monitoring, fault diagnosis, and PC connectivity via USB.

Key Features

• Genuine ABB original – for ACS880, ACS580, ACS380, ACQ810, ACSM1 series
• High-resolution graphical display with backlight
• Context-sensitive help and assistant-guided start-up
• Parameter copy and backup between drives (up to 10 drives)
• Real-time monitoring: frequency, current, voltage, power, torque, etc.
• Fault logging and diagnostics
• USB port for PC connection (Drive Composer/DriveWare)
• Rugged design – IP54 front protection
• Available variants: ACS-AP-W (English/Multilingual), ACS-AP-S (English), ACS-AP-I (Chinese), ACS-AP-H (Handwriting)
• New original – factory sealed

Specifications

Variant Comparison

Compatibility Note

• Compatible with ACS880, ACS580, ACS380, ACQ810, ACSM1 series drives
• Plugs into front-panel RJ-45 connector (panel bus)
• Supports hot-swap – can be plugged/unplugged while drive is powered
• For multiple drives in a panel bus network, total cable length ≤100 m
• Not compatible with ACS800 series (uses CDP-312R)
• Verify drive model and firmware version before ordering

Quality Assurance

• New original – factory sealed packaging
• Actual photos sent before shipping
• Test video available upon request
• ESD anti-static packaging
