ABB BGAD-21C Gate Driver Board with FS500R17OE4D_B61 IGBT Module – 1700V 500A – New Original

Product Overview

Original ABB BGAD-21C gate driver board with FS500R17OE4D_B61 IGBT power module. The FS500R17OE4D is an Infineon EconoPACK+ D-series 1700V/500A six-pack IGBT module with Trench/Fieldstop IGBT4 technology. The BGAD-21C is ABB’s dedicated gate driver board that interfaces directly with the module. The “B61” suffix indicates the product version of the IGBT module. This matched kit forms the core of ABB ACS880 and ACS800 high-power drive power units.

Key Features

• Genuine ABB kit – BGAD-21C gate driver board + FS500R17OE4D_B61 IGBT module
• IGBT: 1700V / 500A continuous (1000A peak) six-pack configuration
• Infineon EconoPACK+ D package with TRENCHSTOP IGBT4 technology
• Integrated gate driver with protection circuits – overcurrent, overvoltage, overtemperature
• Integrated NTC thermistor for temperature monitoring
• High short-circuit capability and self-limiting short-circuit current
• Isolated base plate – simplifies mounting
• Switching frequency: up to 20-25 kHz (application dependent)
• Matched pair – factory-tuned for optimal switching performance
• New original – factory sealed

Specifications

Compatibility Note

• Compatible with ACS880 series drives (R6i-R8i frames)
• Also used in ACS800 series high-voltage drives
• Specifically for 1700V (-7 suffix) drive models – not for 1200V versions
• Matched kit – driver and IGBT are factory-tuned as a pair
• Important: “B61” is the product version of the IGBT module
• Verify drive model, hardware version, and original part numbers before ordering
• Send drive nameplate photo for accurate matching

Quality Assurance

• New original – factory sealed packaging
• Actual photos sent before shipping
• Test video available upon request
• ESD anti-static packaging
