ABB FS450R17KE3/AGDR-71C IGBT Module + Gate Driver Kit – 1700V 450A – New Original

Product Overview

Original ABB FS450R17KE3/AGDR-71C IGBT power module and gate driver kit. The FS450R17KE3 is an Infineon EconoPACK+ 1700V/450A six-pack IGBT module. The AGDR-71C is ABB’s dedicated gate driver board that interfaces directly with the module, converting fiber-optic PWM signals from the main control board into high-current gate drive pulses. This matched kit forms the core of ABB ACS800 and ACS880 high-power drive power units.

Key Features

• Genuine ABB kit – FS450R17KE3 IGBT module + AGDR-71C gate driver board
• IGBT: 1700V / 450A continuous (605A @ Tc=25°C) six-pack configuration
• Infineon EconoPACK+ package with Trench/Fieldstop IGBT3 technology
• AGDR-71C driver: fiber-optic PWM input, +15V/-8V gate drive
• Built-in Desat short-circuit protection (<1 µs response) and Miller clamp
• Integrated NTC thermistor for temperature monitoring
• Matched pair – factory-tuned for optimal switching performance
• New original – factory sealed

Specifications

Compatibility Note

• Compatible with ACS800 and ACS880 series high-power drives
• Specifically for 1700V (-7 suffix) drive models – not for 1200V versions
• Matched kit – IGBT and driver are factory-tuned as a pair
• Verify drive model, hardware version, and original part numbers before ordering
• Send drive nameplate photo for accurate matching

Quality Assurance

• New original – factory sealed packaging
• Actual photos sent before shipping
• Test video available upon request
• ESD anti-static packaging
