Danfoss 130B7260 Power/Driver Board – FC302/202/102/111/360/361 90-500KW – Tested

Product Overview

Original Danfoss 130B7260 power and driver board for VLT AutomationDrive FC302, FC202, FC102, FC111, FC360, and FC361 series drives. Covers a wide power range from 90KW to 500KW. This board houses the main DSP processor that executes PWM vector control algorithms. It also manages all digital and analog I/O, includes integrated communication ports and option card slots, and serves as the base board for the LCP control panel. Available in multiple revision variants. Nameplate photo required for accurate matching.

Key Features

• Genuine Danfoss original – 130B7260 power/driver board
• Compatible with FC302, FC202, FC102, FC111, FC360, and FC361 series
• Power ratings: 90KW – 500KW (all ratings available)
• Multiple revision variants: DT/04, DT/08, DT/09, and others
• Houses main DSP processor – executes PWM vector control algorithms
• Manages all digital and analog I/O – speed reference, start/stop, relay outputs, 0-10V, 4-20mA
• Includes integrated communication ports (RS-485, USB) and option card slots (PROFIBUS, PROFINET, Ethernet/IP)
• Base board for LCP (Local Control Panel) connection
• Continuous monitoring: overcurrent, overtemperature, overvoltage, undervoltage protection
• Input voltage: 3×380-500V AC (T5) / 3×525-690V AC (T7)
• Weight: ~0.45 kg
• Original pulled – no repair history

Specifications

Compatibility Note

• Compatible with Danfoss VLT AutomationDrive FC302, FC202, FC102, FC111, FC360, and FC361 series drives
• Power ratings from 90KW to 500KW – all available
• CRITICAL: Nameplate photo required – different power ratings and drive versions use different board revisions (DT/04, DT/08, DT/09, etc.)
• Order codes referenced: 176F3140, 176F3141, 176F3142[reference:9]
• Used in FC-302N355T5 configurations with 130B7260 DT/08/R1[reference:10][reference:11]
• Verify drive model, power rating, and revision before ordering
• Send drive nameplate photo for accurate matching

Quality Assurance

• Original pulled from working drive; tested functional with no repair history
• Actual photos sent before shipping
• Test video available upon request
• ESD anti-static packaging
