Schneider EAV97603-00 Main Power Plate – ATV660 315–400kW

What Is the EAV97603-00?

The Schneider Electric EAV97603-00 is identified as a main positive / negative power plate used in selected Altivar Process variable frequency drive systems.

It is an internal power distribution component associated with the main power connections of industrial VFD equipment.

This component is listed for selected ATV610 and ATV660 drive applications in the 315kW to 400kW range.

This unit is offered as tested stock for industrial drive maintenance and replacement applications.

Before ordering, verify the original part number, drive model and power connection configuration to ensure correct replacement compatibility.

Key Specifications

Specification	Details
Part Number	EAV97603-00
Alternative Part Number Format	EAV97603_00
Brand	Schneider Electric
Product Type	Main Positive / Negative Power Plate
Drive Series	ATV610 / ATV660 (specific models to be verified)
Related Application Range	315kW / 400kW
Condition	Tested Stock
Testing Status	Tested; confirm available test details before ordering
Application	Industrial VFD Power Distribution and Replacement

Applications and Compatibility

The Schneider EAV97603-00 is listed for selected high-power Schneider Altivar Process drive applications.

Available supplier references associate this component with:

• ATV610 – selected 315kW / 400kW configurations.
• ATV660 – selected 315kW / 400kW configurations.

ATV680 and ATV6B0 are also Schneider Altivar Process drive families. However, direct compatibility with EAV97603-00 has not been independently confirmed.

Important Compatibility Checks:

Before ordering, verify:

• Confirm that the original component carries the part number EAV97603-00.
• Check the complete ATV610 / ATV660 / ATV680 / ATV6B0 drive reference.
• Verify the drive power rating and voltage class.
• Compare the positive and negative power connection layout.
• Check mounting positions and physical dimensions.
• Confirm the original power assembly configuration.

Do not assume that all 315kW and 400kW drives use the same power plate.

How to Identify the Correct Replacement Power Plate

When replacing a main power plate, carefully compare the original component with the replacement unit.

Check the following details:

• Part number printed on the original component.
• Positive and negative terminal identification.
• Power connection layout.
• Mounting positions and dimensions.
• Insulation structure and connection points.
• Complete drive model and nameplate information.

If you are unsure about compatibility, send us clear photos of the existing component and the drive nameplate before ordering.

When Should the Main Power Plate Be Replaced?

A main power plate may require inspection when the inverter experiences abnormal power connections or visible damage to its main power distribution components.

Before replacement:

• Inspect the positive and negative connection areas.
• Check for visible cracks, damage or overheating.
• Inspect terminal contact surfaces.
• Check mounting points and insulation condition.
• Verify that the replacement component matches the original configuration.

A drive fault does not automatically mean the power plate is defective. Other power circuit components and connections should also be inspected by qualified personnel.

Condition and Testing

This product is offered as tested stock for industrial inverter maintenance and replacement.

Please contact us for available inspection and testing details, actual product photos and current stock availability.

Confirm the physical condition and testing scope before purchase.

Frequently Asked Questions

What is the EAV97603-00 used for?

The EAV97603-00 is identified as a main positive / negative power plate for selected Schneider Altivar Process drive applications.

Is EAV97603-00 suitable for 315kW and 400kW drives?

Supplier listings associate this component with selected ATV610 and ATV660 315kW / 400kW applications. Always verify the complete drive reference before ordering.

Is EAV97603-00 compatible with ATV680 and ATV6B0?

These are Schneider Altivar Process drive families, but compatibility with this exact power plate should be confirmed against the original equipment configuration before purchase.

Is this component tested?

This listing is for tested stock. Please request available inspection and functional testing details before ordering.

Need Help Confirming Compatibility?

Looking for a replacement Schneider EAV97603-00 main power plate?

Send us:

• A clear photo of the existing power plate.
• A close-up photo of the part number label.
• Photos of the positive and negative power connections.
• The complete Schneider drive nameplate.
• Your required quantity.

Contact us for product identification, compatibility assistance and quotation.
