Schneider NHA50709-01-00 Power Board – ATV610/630/930 110–160kW

What Is the NHA50709-01-00?

The Schneider Electric NHA50709-01-00 is a power board used in selected Altivar Process variable frequency drive configurations.

It is an internal electronic component intended for industrial VFD maintenance, repair and replacement applications.

This board is listed for selected ATV610, ATV630 and ATV930 drive configurations with power ratings of 110kW, 132kW and 160kW.

It is offered as tested stock for customers requiring a replacement Schneider power board.

Before ordering, verify the complete original board number and drive model to ensure correct replacement compatibility.

Key Specifications

Specification	Details
Part Number	NHA50709-01-00
Brand	Schneider Electric
Product Type	VFD Power Board
Drive Series	ATV610 / ATV630 / ATV930
Application Power Ratings	110kW / 132kW / 160kW
Condition	Tested Stock
Testing Status	Tested; confirm available test details before ordering
Application	Industrial VFD Power Board Maintenance and Replacement

Applications and Compatibility

The Schneider NHA50709-01-00 is listed for selected Schneider Altivar Process ATV610, ATV630 and ATV930 variable frequency drive applications.

Available supplier references associate this power board with:

• ATV610 – selected 110kW / 132kW / 160kW configurations.
• ATV630 – selected 110kW / 132kW / 160kW configurations.
• ATV930 – selected 110kW / 132kW / 160kW configurations.

These are reference applications, not a guarantee of compatibility with every drive in these series.

Important Compatibility Checks:

Before ordering, verify:

• Confirm that the original board carries the complete part number NHA50709-01-00.
• Check the complete ATV610 / ATV630 / ATV930 drive model.
• Verify the drive power rating and voltage class.
• Compare the board revision and identification markings.
• Check connector positions and pin configuration.
• Compare the original board layout and mounting points.

Do not assume that every 110kW, 132kW or 160kW drive uses the same power board.

How to Identify the Correct Replacement Power Board

When replacing a power board, carefully compare the existing board with the replacement unit.

Check the following details:

• Part number printed on the original PCB.
• Board revision and identification labels.
• Connector positions and pin configuration.
• Electronic component layout.
• Mounting positions and electrical connections.
• Complete drive model and nameplate information.

If you are unsure about compatibility, send us clear photos of the existing board and the drive nameplate before ordering.

When Should the Power Board Be Replaced?

A power board may require inspection when the inverter experiences abnormal power conversion or power-stage operation.

Before replacing the board:

• Inspect the board for visible damage or burnt components.
• Check connectors and electrical connections.
• Inspect the associated power electronics.
• Review the drive fault history and diagnostic results.
• Verify that the replacement part number matches the original board.

A drive fault does not automatically mean the power board is defective. Other power circuit components and connections should also be inspected by qualified personnel.

Condition and Testing

This product is offered as tested stock for industrial inverter maintenance and replacement.

Please contact us for available testing details, actual product photos and current stock availability.

Confirm the physical condition and testing scope before purchase.

Frequently Asked Questions

What is the NHA50709-01-00 used for?

The NHA50709-01-00 is a Schneider Electric VFD power board listed for selected Altivar ATV610, ATV630 and ATV930 drive applications.

Which power ratings are associated with NHA50709-01-00?

Available supplier listings associate this board with 110kW, 132kW and 160kW drive applications. Always verify the complete drive reference before ordering.

Is NHA50709-01-00 compatible with all ATV610, ATV630 and ATV930 drives?

No universal compatibility is confirmed. Compatibility depends on the exact drive model, power configuration and original board identification.

Is NHA50709-01-00 the same as NHA50709-01?

Do not assume that different part number formats or suffixes indicate interchangeable boards. Compare the complete identification label and hardware configuration before replacement.

Is this power board tested?

This listing is for tested stock. Please request available inspection and functional testing details before purchase.

Need Help Confirming Compatibility?

Looking for a replacement Schneider NHA50709-01-00 power board?

Send us:

• A clear photo of the existing power board.
• A close-up photo of the NHA50709-01-00 identification label.
• The complete ATV610 / ATV630 / ATV930 drive nameplate.
• The drive model, power rating and voltage.
• Your required quantity.

Contact us for product identification, compatibility assistance and quotation.
