Schneider NHA75769_02 Power Board – ATV630/930 220–315kW

What Is the NHA75769_02?

The Schneider Electric NHA75769_02 is a power board used in selected Altivar Process variable frequency drive configurations.

It is an internal power electronics component designed for high-power industrial VFD applications, maintenance and replacement.

This board is listed for selected ATV630 and ATV930 drive configurations with power ratings of 220kW, 250kW and 315kW.

It is supplied as new original stock for customers requiring a replacement power board.

Before ordering, verify the original board identification and complete drive model to ensure correct replacement compatibility.

Key Specifications

Specification	Details
Part Number	NHA75769_02
Brand	Schneider Electric
Product Type	Power Board / Power Control Board
Drive Series	Altivar Process ATV630 / ATV930
Additional Compatibility	Selected ATV610 configurations (verify exact model)
Application Power Range	220kW / 250kW / 315kW
Voltage Class	380–480V AC, 3-phase (verify drive nameplate)
Condition	New Original Stock
Testing Status	Not specified; confirm before ordering
Application	Industrial VFD Power Board Replacement

Applications and Compatibility

The Schneider NHA75769_02 is listed as a power board for selected Altivar Process ATV630 and ATV930 variable frequency drives.

Available supplier references associate this board with:

• ATV630 – selected 220kW / 250kW / 315kW configurations.
• ATV930 – selected high-power drive configurations.
• ATV610 – selected configurations requiring individual compatibility verification.

The listed application power ratings are 220kW, 250kW and 315kW.

Important Compatibility Checks:

Before ordering, verify:

• Confirm that the original board carries the complete part number NHA75769_02.
• Check the complete Schneider drive model and catalog reference.
• Verify the drive power rating and voltage class.
• Compare the board revision and identification markings.
• Check connector positions and pin configuration.
• Compare the original board layout and mounting points.

Do not assume that every ATV610, ATV630 or ATV930 drive with a 220–315kW rating uses the same power board.

How to Identify the Correct Replacement Power Board

When replacing a power board, carefully compare the original board with the replacement unit.

Check the following details:

• Part number printed on the original PCB.
• Board revision and identification markings.
• Connector positions and pin configuration.
• Electronic component layout.
• Mounting positions and electrical connections.
• Complete drive model and nameplate information.

If you are unsure about compatibility, send us clear photos of the existing board and the drive nameplate before ordering.

When Should the Power Board Be Replaced?

A power board may require inspection when the inverter experiences abnormal power conversion or power-stage operation.

Before replacing the board:

• Inspect the board for visible damage or burnt components.
• Check connectors and electrical connections.
• Inspect the associated power electronics.
• Review the drive fault history and diagnostic results.
• Verify that the replacement part number matches the original board.

A drive fault does not automatically mean the power board is defective. Other power circuit components and connections should also be inspected by qualified personnel.

Condition and Testing

This product is offered as new original Schneider Electric stock.

It is intended for industrial inverter maintenance, repair and replacement applications.

Please confirm the actual packaging, product identification label and physical condition before purchase.

Functional testing status should be confirmed separately. New original stock should not automatically be described as tested.

Frequently Asked Questions

What is the NHA75769_02 used for?

The NHA75769_02 is a Schneider Electric power board used in selected Altivar Process ATV630 and ATV930 variable frequency drive applications.

Which power ratings are associated with NHA75769_02?

Available supplier listings associate this board with 220kW, 250kW and 315kW drive applications. Always verify the complete drive reference before ordering.

Is NHA75769_02 compatible with ATV610 drives?

Some supplier listings include selected ATV610 configurations. However, compatibility should be verified against the exact drive model and original board identification.

Is NHA75769_02 a power board or a control board?

It is listed as a power board / power control board. It should not be confused with the main CPU control board or other inverter circuit boards.

Is this board new or tested?

This listing is for new original stock. Please confirm the packaging and condition of the actual unit before ordering.

Need Help Confirming Compatibility?

Looking for a replacement Schneider NHA75769_02 power board?

Send us:

• A clear photo of the existing power board.
• A close-up photo of the NHA75769_02 identification label.
• The complete ATV630 / ATV930 drive nameplate.
• The drive model, power rating and voltage.
• Your required quantity.

Contact us for product identification, compatibility assistance and quotation.
