Schneider PN072125P3 Gate Driver Board – ATV61/ATV71 160–315kW

What Is the PN072125P3?

The Schneider Electric PN072125P3 is an IGBT gate driver / power drive board used in selected Altivar 61 and Altivar 71 high-power variable frequency drive configurations.

It is an internal electronic board associated with the IGBT power control system and is intended for industrial inverter maintenance, repair and replacement applications.

This board is listed for selected ATV61 and ATV71 drive applications with power ratings of 160kW, 200kW, 250kW and 315kW.

It is offered as tested stock for customers requiring a replacement Schneider gate driver board.

Before ordering, verify the original board number, complete drive model and IGBT configuration to ensure correct replacement compatibility.

Key Specifications

Specification	Details
Part Number	PN072125P3
Brand	Schneider Electric
Product Type	IGBT Gate Driver / Power Drive Board
Drive Series	Altivar 61 / Altivar 71
Listed Application Power Ratings	160kW / 200kW / 250kW / 315kW
Related Supplier Reference	VX5A1201 (verify before substitution)
Condition	Tested Stock
Testing Status	Tested; confirm available test details before ordering
Application	High-Power Industrial VFD Maintenance and Replacement

Applications and Compatibility

The Schneider PN072125P3 is listed for selected high-power Altivar 61 and Altivar 71 inverter applications.

Available supplier references associate this board with the following drive power ratings:

• 160kW
• 200kW
• 250kW
• 315kW

One industrial spare parts supplier specifically identifies PN072125P3 / VX5A1201 as a gate driver board for the ATV61HC22N4 drive.

Important Compatibility Checks:

Before ordering, verify:

• Confirm that the original board carries the exact part number PN072125P3.
• Check the complete ATV61 / ATV71 drive model.
• Verify the drive power rating and voltage class.
• Compare the original board revision and identification markings.
• Check connector positions and pin configuration.
• Verify the IGBT manufacturer and power configuration.
• Confirm whether the original board requires an additional F suffix.

Do not assume that every 160kW, 200kW, 250kW or 315kW ATV61 / ATV71 drive uses the same gate driver board.

Important IGBT Version Check:

Some ATV61 drives use Fuji IGBTs instead of standard Mitsubishi IGBTs.

According to Schneider Electric, if the eighth digit of the drive serial number is 2, the drive uses Fuji IGBTs. Relevant replacement power boards, IGBTs, measuring boards and gate driver boards may require an additional F suffix.

Always verify the original board version and drive serial number before ordering.

How to Identify the Correct Replacement Board

When replacing an IGBT gate driver board, carefully compare the existing board with the replacement unit.

Check the following details:

• Part number printed on the original PCB.
• Board revision and identification labels.
• IGBT configuration and related hardware.
• Connector positions and pin configuration.
• Electronic component layout.
• Mounting positions and electrical connections.
• Complete drive model and serial number.

If you are unsure about compatibility, send us clear photos of the existing board and drive nameplate before ordering.

When Should the Gate Driver Board Be Replaced?

A gate driver board may require inspection when the inverter experiences IGBT-related faults or abnormal power-stage operation.

Before replacing the board:

• Inspect the board for visible damage or burnt components.
• Check connectors and electrical connections.
• Inspect the associated IGBT power modules.
• Review the drive fault history and diagnostic results.
• Verify the correct board number and hardware version.

A drive fault does not automatically mean the gate driver board is defective. The IGBT modules, power connections and other drive circuits should also be inspected by qualified personnel.

Condition and Testing

This product is offered as tested stock for industrial inverter maintenance and replacement.

Please contact us for available inspection and functional testing details, actual product photos and current stock availability.

Confirm the physical condition and testing scope before purchase.

Frequently Asked Questions

What is the PN072125P3 used for?

The PN072125P3 is an IGBT gate driver / power drive board listed for selected Schneider Altivar 61 and Altivar 71 high-power inverter applications.

Which power ratings are associated with PN072125P3?

Supplier listings associate this board with 160kW, 200kW, 250kW and 315kW drive applications. Always verify the complete drive reference before ordering.

Is PN072125P3 related to VX5A1201?

Some supplier listings associate PN072125P3 with VX5A1201. However, do not assume that different part number references are interchangeable without checking the original board identification and hardware configuration.

Does the IGBT version affect board compatibility?

Yes. Certain ATV61 drives use Fuji IGBTs instead of Mitsubishi IGBTs. Check the drive serial number and original board suffix before selecting a replacement.

Is this board tested?

This listing is for tested stock. Please request available inspection and functional testing details before purchase.

Need Help Confirming Compatibility?

Looking for a replacement Schneider PN072125P3 IGBT gate driver board?

Send us:

• A clear photo of the existing board.
• A close-up photo of the PN072125P3 identification label.
• The complete ATV61 / ATV71 drive nameplate.
• The drive serial number.
• Your required quantity.

Contact us for product identification, compatibility assistance and quotation.
