Schneider PN072128P4 Power/Driver Board – ATV61/71 160-315KW – Original Pulled

Product Overview

Original Schneider PN072128P4 power and driver board for Altivar ATV61 and ATV71 series drives. This board serves as the core power stage component, integrating IGBT gate driver circuitry, DC bus voltage regulation, and power supply distribution. Also referenced with part number VX5A1HC2531 and related model PN072128P3.

Key Features

• Genuine Schneider original – PN072128P4 power/driver board
• Compatible with Altivar ATV61 and ATV71 series drives
• Power ratings: 160KW – 200KW – 220KW – 250KW – 315KW
• Voltage: 3-phase 380-480V AC
• Also referenced as VX5A1HC2531
• Core power stage component – IGBT gate drive and DC bus regulation
• Designed for heavy industrial applications – cranes, textile machinery, material handling, process control
• Weight: ~2 kg
• Country of origin: France
• Original pulled – no repair history

Specifications

Compatibility Note

• Compatible with Schneider Altivar ATV61, ATV71, ATV61F, ATV61 Plus, and ATV71 Plus series drives
• Specifically for 160KW, 200KW, 220KW, 250KW, and 315KW power ratings at 380-480V AC
• Alternative part number: VX5A1HC2531 – verify original board marking
• Related model: PN072128P3 (earlier revision) – verify exact marking before ordering
• Also compatible with ATV71HC16N4 (160KW / 480V) configurations
• CRITICAL: Nameplate photo required – different power ratings and drive versions may use different board revisions
• If mismatched: Incorrect board selection may result in drive failing to power up, reporting “DC Bus Fault,” or experiencing IGBT drive errors
• Verify drive model, power rating, and original board marking before ordering
• Send drive nameplate photo for accurate matching

Quality Assurance

• Original pulled from working drive; tested functional with no repair history
• Actual photos sent before shipping
• Test video available upon request
• ESD anti-static packaging
