Schneider PN072410P2 IGBT Trigger Board – ATV61 690V

What Is the PN072410P2?

The Schneider Electric PN072410P2 is an IGBT trigger / gate driver board used in specific Altivar 61 variable frequency drive configurations.

It is part of the drive’s internal IGBT control system and is designed to work with the power electronics assembly. It is not a main control board or a complete inverter.

This unit is supplied as Tested Stock. It is intended for maintenance, repair and replacement applications.

Key Specifications

Specification	Details
Part Number	PN072410P2
Brand	Schneider Electric
Product Type	IGBT Trigger / Gate Driver Board
Drive Series	Altivar 61 (ATV61)
Voltage Class	690V
Application Power Range	500–630kW (verify exact drive reference)
Condition	Tested Stock
Testing Status	Tested; confirm available test details before ordering

Applications and Compatibility

The PN072410P2 is identified as a Schneider inverter driver trigger board for Altivar 61 drive applications.

Before ordering, verify the complete drive configuration rather than relying on the ATV61 series name alone.

Check the following information:

• Complete ATV61 drive model and catalog reference.
• Drive voltage and power rating.
• Drive serial number.
• Existing gate driver board part number.
• IGBT type and board revision.
• Connector positions and configuration.

Important – IGBT Version Compatibility:

Schneider Electric states that certain ATV61 drives use Fuji IGBTs instead of standard Mitsubishi IGBTs. For drives with Fuji IGBTs, the corresponding IGBT, measuring board and gate driver board part numbers have an additional F suffix.

Check the 8th digit of the drive serial number and verify the correct board version before ordering.

Do not assume that PN072410P2 fits every ATV61 690V drive.

When Should the IGBT Trigger Board Be Replaced?

A gate driver board may require inspection when the drive experiences IGBT-related faults or power-stage operating problems.

Before replacing the board:

• Check the existing board for visible damage or burnt components.
• Inspect connectors and connection points.
• Check the corresponding IGBT power module.
• Verify the drive’s fault history and diagnostic results.
• Confirm the replacement board number and hardware version.

Fault symptoms alone do not prove that the trigger board is defective. The power module, connections and other drive circuits should also be checked.

Product Identification and Replacement Check

To help identify the correct replacement, compare:

• PN072410P2 part number printed on the original board.
• Board revision and any suffix.
• IGBT configuration.
• Connector layout.
• Complete ATV61 drive nameplate and serial number.

If you are unsure about compatibility, send us photos of the existing board label, connectors and drive nameplate before ordering.

Condition and Testing

This product is offered as tested stock for industrial inverter maintenance and replacement.

Please contact us for available product photos and testing details before purchase.

Confirm the actual board condition and testing scope when requesting a quotation.

Frequently Asked Questions

Is PN072410P2 an IGBT driver board or a main control board?

PN072410P2 is identified as an inverter driver trigger board. It should not be confused with the main control board.

Is PN072410P2 compatible with all ATV61 690V drives?

No. Compatibility depends on the exact drive configuration, IGBT type, serial number and board version. Always verify the original part number before ordering.

How can I identify the correct PN072410P2 replacement?

Check the part number on the original board and provide the complete ATV61 drive nameplate and serial number. Connector and board revision details should also be compared.

Is this board tested?

This listing is for tested stock. Please request the available testing details before purchase.

Need Help Confirming Compatibility?

Looking for a replacement Schneider PN072410P2 IGBT trigger board?

Send us:

• A clear photo of the existing board.
• A photo of the PN072410P2 part number label.
• The complete ATV61 drive model.
• The drive serial number.
• Your required quantity.

Contact us for compatibility assistance, availability and quotation.
