Schneider PN072418P2 Detection/Power Board – ATV61/71 690V 400-500KW – Tested

Product Overview

Original Schneider PN072418P2 detection and power board for Altivar ATV61 and ATV71 series high-power drives. This board serves as a detection and measurement component, responsible for DC bus voltage measurement and balancing within the drive’s power circuit. Also referenced as a “balancing board” in Schneider’s spare parts documentation.

Key Features

• Genuine Schneider original – PN072418P2 detection/power board
• Compatible with Altivar ATV61 and ATV71 series drives
• Voltage class: 690V AC (500V to 690V range)
• Power ratings: 400KW – 500KW
• Also referenced as “balancing board” (平衡板) for DC bus voltage measurement
• Essential for DC bus voltage measurement and balancing in high-power drive circuits
• Used in ATV61/71 690V high-power drive systems
• 9/10 condition – minimal signs of use
• Original pulled – no repair history

Specifications

Compatibility Note

• Compatible with Schneider Altivar ATV61 and ATV71 series drives
• Specifically for 690V AC systems with 400KW to 500KW power ratings
• Typical drive models: ATV61HC50Y (500KW @ 690V), ATV61HC40Y (400KW @ 690V)
• CRITICAL: Nameplate photo required – different power ratings and drive versions may use different board variants
• If mismatched: Incorrect board selection may result in drive failing to power up, reporting “DC Bus Fault,” or experiencing voltage measurement errors
• This board is also referenced as a “balancing board”  in Schneider’s spare parts documentation, reflecting its function in DC bus voltage balancing
• Related part numbers in the same family: PN072416P3, PN072410P2, PN072411P2 – verify original board marking
• Verify drive model, power rating, and original board marking before ordering
• Send drive nameplate photo for accurate matching

Quality Assurance

• 9/10 condition – original pulled from working drive; fully functional with minimal signs of use
• Tested with no repair history
• Actual photos sent before shipping
• Test video available upon request
• ESD anti-static packaging
